Descriptions of Omron G3R-IDZR1SN-UTU 12-24DC provided by its distributors.
Relay SSR 8mA 24V DC-IN 100mA 32V DC-OUT 4-Pin
Avnet Japan
Solid State Relay, 0.1A, 12-24V, Socket; Contact Configuration:-; Load Current:100Ma; Operating Voltage Max:32Vdc; Relay Mounting:Socket; Relay Terminals:Quick Connect; Switching Mode:-; Operating Voltage Min:6.6Vdc; Control Voltage Rohs Compliant: Yes |Omron G3R-IDZR1SN-UTU 12-24DC
Termination Type = Push-In Terminal / Mounting Type = Socket Mount / Width mm = 13 / Series = G3R / Length mm = 29 / Load Voltage Max. V = 32 / Frequency Max. Hz = 60 / Load Current Max. mA = 100 / Load Voltage Min. V = 4 / Load Current Min. uA = 100 / Switching Function = Zero Cross Switching / Control Voltage Min. V = 6.6 / Control Voltage Max. V = 32 / Height mm = 28 / Frequency Min. Hz = 50
