| MAİN | |
|---|---|
| Range of product | OsiSense XC |
| Series name | Basic |
| Product or component type | Limit switch |
| Product specific application | Light to medium duty |
| Device short name | XCJ |
| Body type | Fixed |
| Head type | Plunger head |
| Material | Plastic |
| Fixing mode | By the body |
| Movement of operating head | Linear |
| Type of operator | Roller lever plunger thermoplastic long and flat |
| Switch actuation | By 30° cam |
| Type of approach | Lateral approach, 1 direction |
| Electrical connection | Screw-clamp terminals |
| Cable entry | 1 flexible rubber cable gland, cable outer diameter: 8.5…10.5 mm |
| Number of poles | 1 |
| Contact operation | Snap action |
| Positive opening | Without |
| Maximum force for tripping | 1.6 N |
| COMPLEMENTARY | |
| Contacts insulation form | C |
| Minimum release force | 0.49 N |
| Minimum actuation speed | 0.01 mm/s |
| Maximum actuation speed | 0.5 m/s |
| Maximum operating rate | 120 cyc/mn |
| Contact code designation | A300, AC (Ue = 240 V), Ie = 10 A, Ithe = 10 A conforming to IEC 60947-5-1 R300, DC (Ue = 220 V), Ie = 0.3 A conforming to IEC 60947-5-1 |
| Maximum resistance across terminals | 25 MOhm |
| [Uimp] rated impulse withstand voltage | 4 kV conforming to EN/IEC 60664 |
| Electrical durability | 800000 cycles, AC, 10 A, 220 V |
| Mechanical durability | 10000000 cycles |
| Width | 22 mm |
| Height | 64 mm |
| Depth | 72 mm |
| Net weight | 0.060 kg |
| Terminals description ISO n°1 | (NO-NC-C)OF |
| ENVİRONMENT | |
| Shock resistance | 10 gn for 11 ms conforming to IEC 60068-2-27 |
| Vibration resistance | +/- 0.7 mm (f= 10…55 Hz) conforming to IEC 60068-2-6 |
| IP degree of protection | IP40 conforming to IEC 60529 |
| Electrical shock protection class | Class II conforming to EN/IEC 60947-5-1 |
| Ambient air temperature for operation | -25…70 °C |
| Ambient air temperature for storage | -40…70 °C |
| Marking | CE CCC |
| Standards | IEC 60947-5-1 GB 14048.5 |
| PACKİNG UNİTS | |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 2.000 cm |
| Package 1 Width | 6.500 cm |
| Package 1 Length | 7.000 cm |
| Package 1 Weight | 63.000 g |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 150 |
| Package 2 Height | 30.000 cm |
| Package 2 Width | 30.000 cm |
| Package 2 Length | 40.000 cm |
| Package 2 Weight | 10.602 kg |
| Unit Type of Package 3 | P06 |
| Number of Units in Package 3 | 1200 |
| Package 3 Height | 75.000 cm |
| Package 3 Width | 80.000 cm |
| Package 3 Length | 60.000 cm |
| Package 3 Weight | 92.816 kg |
