| Assembly style | For customer assembly |
|---|
| Net weight | 0.013 kg |
|---|
| Contact operation | Slow-break |
|---|
| Positive opening | With conforming to IEC 60947-5-1 section 3 |
|---|
| Operating force | 0.8 N NC changing electrical state |
|---|
| Connections - terminals | Screw clamp terminals, <= 2 x 1.5 mm² without cable end
Screw clamp terminals, >= 1 x 0.22 mm² with cable end |
|---|
| Short-circuit protection | 10 A cartridge fuse type gL conforming to IEC 60269-1
10 A cartridge fuse type gL conforming to VDE 0660-200 |
|---|
| [Ui] rated insulation voltage | 500 V (pollution degree 3) conforming to IEC 60947-1
600 V conforming to UL 508
600 V conforming to CSA C22.2 No 14 |
|---|
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947-1 |
|---|
| [Ie] rated operational current | 3 A at 240 V, AC-15, A600
0.27 A at 250 V, DC-13, Q600 conforming to IEC 60947-5-1 appendix A |
|---|
| Electrical durability | 1000000 cycles, DC-13 at 120 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to IEC 60947-5-1 appendix C
1000000 cycles, DC-13 at 24 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to IEC 60947-5-1 appendix C
1000000 cycles, DC-13 at 48 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to IEC 60947-5-1 appendix C |
|---|
| Electrical reliability | Λ < 10exp(-6)
Λ < 10exp(-8) |
|---|
