| Assembly style |
For customer assembly |
| Net weight |
0.013 kg |
| Contact operation |
Slow-break |
| Positive opening |
With conforming to IEC 60947-5-1 section 3 |
| Operating force |
0.8 N NC changing electrical state |
| Connections - terminals |
Screw clamp terminals, <= 2 x 1.5 mm² without cable end
Screw clamp terminals, >= 1 x 0.22 mm² with cable end |
| Short-circuit protection |
10 A cartridge fuse type gL conforming to IEC 60269-1
10 A cartridge fuse type gL conforming to VDE 0660-200 |
| [Ui] rated insulation voltage |
500 V (pollution degree 3) conforming to IEC 60947-1
600 V conforming to UL 508
600 V conforming to CSA C22.2 No 14 |
| [Uimp] rated impulse withstand voltage |
6 kV conforming to IEC 60947-1 |
| [Ie] rated operational current |
3 A at 240 V, AC-15, A600
0.27 A at 250 V, DC-13, Q600 conforming to IEC 60947-5-1 appendix A |
| Electrical durability |
1000000 cycles, DC-13 at 120 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to IEC 60947-5-1 appendix C
1000000 cycles, DC-13 at 24 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to IEC 60947-5-1 appendix C
1000000 cycles, DC-13 at 48 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to IEC 60947-5-1 appendix C |
| Electrical reliability |
Λ < 10exp(-6)
Λ < 10exp(-8) |
